Infitek MSC-M60X Metallurgical Microscope
MSC-M60X
Metallurgical Microscope MSC-M60X dilengkapi eyepiece bidang luas WF10X/FN 22 dengan diopter yang dapat disetel, nosepiece kuintuple, fungsi ECO mati otomatis dan voice broadcast, serta diafragma aperture, diafragma bidang, dan dudukan filter.
Yang akan anda dapatkan jika membeli Infitek MSC-M60X Metallurgical Microscope dari kami
- ✓
Garansi Resmi Prinsipal
Unit didistribusikan resmi dengan garansi prinsipal sesuai ketentuan pabrikan.
- ✓
Instalasi & Training
Teknisi kami membantu instalasi dan pelatihan penggunaan alat di lokasi Anda.
- ✓
Dukungan Teknis & Sparepart
Layanan purna jual, konsultasi teknis, dan ketersediaan suku cadang.
- ✓
Opsi Kalibrasi
Tersedia layanan kalibrasi tertelusur untuk menjaga akurasi instrumen.
Spesifikasi Teknis
| Parameter | MSC-M60X |
|---|---|
| Main Frame | Infinity-corrected optical system, with ECO automatic light-off and voice broadcast function |
| Observation Tube | Fixed Trinocular head with high eye point, Interpupillary 50~75mm, Light split: 100/0 and 0/100 |
| Viewing Head | Siedentopf head, inclined at 45° |
| Eyepiece | Large field WF10X / FN 22, with adjustable diopter |
| Objectives | Semi-apochromatic brightfield metallurgical objective Plan Fluor EPI 5X/0.15, working distance 20 mm |
| Objectives | Semi-apochromatic brightfield metallurgical objective Plan Fluor EPI 10X/0.3, working distance 11 mm |
| Objectives | Semi-apochromatic brightfield metallurgical objective L Plan 20X/0.45, working distance 3 mm |
| Objectives | Semi-apochromatic brightfield metallurgical objective L Plan 50X/0.8, working distance 1 mm |
| Nosepiece | Inward-facing Quintuple Nosepiece; Ball-bearing positioning; Anti-fungus treatment. |
| Stage | X-Y mechanical metallographic stage; With water droplet plate; |
| Focusing | Coaxial coarse and fine adjustment, with locking and limit device, low-position coaxial focusing knob, fine division 2μm |
| Epi-illumination System | 3W full-spectrum white LED, continuously adjustable brightness With polarization kit for polarized light observation With aperture diaphragm, field diaphragm, and filter holder |
Fitur Utama
- Sistem optik infinity-corrected terintegrasi dengan iluminasi pantulan LED definisi tinggi.
- Sumber cahaya putih spektrum penuh dengan usia pakai sangat panjang dan suhu warna konstan.
- Mendukung pengamatan brightfield dan polarisasi, cocok untuk analisis spesimen logam berukuran besar.
