General Lab
Muffle Furnace FNC-TB1700 Series mencapai suhu maksimum 1700°C untuk pemakaian singkat dengan suhu kerja kontinu ≤1550°C, chamber berbahan alumina ceramic fiber, dan laju pemanasan 0-20°C/menit (disarankan 0-10°C/menit).
Garansi Resmi Prinsipal
Unit didistribusikan resmi dengan garansi prinsipal sesuai ketentuan pabrikan.
Instalasi & Training
Teknisi kami membantu instalasi dan pelatihan penggunaan alat di lokasi Anda.
Dukungan Teknis & Sparepart
Layanan purna jual, konsultasi teknis, dan ketersediaan suku cadang.
Opsi Kalibrasi
Tersedia layanan kalibrasi tertelusur untuk menjaga akurasi instrumen.
Struktur baja dua lapis dengan kipas pendingin udara agar bagian luar furnace aman disentuh;
Safety interlock dengan pemutusan daya otomatis saat pintu furnace dibuka (opsional)
Catatan: Anda hanya dapat memilih salah satu antara opsi 2 dan 3;
Geser tabel ke samping untuk melihat seluruh 13 varian model.
| Parameter | Model Max. Temp(℃) | FNC-TB1700-A2 1700 | FNC-TB1700-B2 1700 | FNC-TB1700-C2 1700 | FNC-TB1700-D2 1700 | FNC-TB1700-A3 1700 | FNC-TB1700-B3 1700 | FNC-TB1700-C3 1700 | FNC-TB1700-D3 1700 | FNC-TB1700-A4 1700 | FNC-TB1700-B4 1700 | FNC-TB1700-C4 1700 | FNC-TB1700-D4 1700 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Temperature | Continuous Working Temp.(℃) | ≤1550 | ≤1550 | ≤1550 | ≤1550 | ≤1550 | ≤1550 | ≤1550 | ≤1550 | ≤1550 | ≤1550 | ≤1550 | ≤1550 |
| Temperature | Heating Rate | 0~20℃/min (suggest to be 0~10℃/min) | 0~20℃/min (suggest to be 0~10℃/min) | 0~20℃/min (suggest to be 0~10℃/min) | 0~20℃/min (suggest to be 0~10℃/min) | 0~20℃/min (suggest to be 0~10℃/min) | 0~20℃/min (suggest to be 0~10℃/min) | 0~20℃/min (suggest to be 0~10℃/min) | 0~20℃/min (suggest to be 0~10℃/min) | 0~20℃/min (suggest to be 0~10℃/min) | 0~20℃/min (suggest to be 0~10℃/min) | 0~20℃/min (suggest to be 0~10℃/min) | 0~20℃/min (suggest to be 0~10℃/min) |
| Temperature | Accuracy(℃) | ±1℃ | ±1℃ | ±1℃ | ±1℃ | ±1℃ | ±1℃ | ±1℃ | ±1℃ | ±1℃ | ±1℃ | ±1℃ | ±1℃ |
| Temperature | Uniformity(℃) | ±5℃ | ±5℃ | ±5℃ | ±5℃ | ±5℃ | ±5℃ | ±5℃ | ±5℃ | ±5℃ | ±5℃ | ±5℃ | ±5℃ |
| Furnace tube material | Furnace tube material | Corundum tube | Corundum tube | Corundum tube | Corundum tube | Corundum tube | Corundum tube | Corundum tube | Corundum tube | Corundum tube | Corundum tube | Corundum tube | Corundum tube |
| Total length of furnace tube | Total length of furnace tube | 800mm | 800mm | 800mm | 800mm | 1000mm | 1000mm | 1000mm | 1000mm | 1200mm | 1200mm | 1200mm | 1200mm |
| Standard Heating zone length | Standard Heating zone length | 205mm | 205mm | 205mm | 205mm | 350mm | 350mm | 350mm | 350mm | 440mm | 440mm | 440mm | 440mm |
| Standard Tube diameter | Standard Tube diameter | ∮40mm | ∮60mm | ∮80mm | ∮100mm | ∮40mm | ∮60mm | ∮80mm | ∮100mm | ∮40mm | ∮60mm | ∮80mm | ∮100mm |
| External Size(W*D*H)(mm) | External Size(W*D*H)(mm) | 630*590*767mm | 630*590*767mm | 630*590*767mm | 630*590*767mm | 724*590*807mm | 724*590*807mm | 724*590*807mm | 724*590*807mm | 794*590*800mm | 794*590*800mm | 794*590*800mm | 794*590*800mm |
| Heating Element | Heating Element | MoSi2 heating rod | MoSi2 heating rod | MoSi2 heating rod | MoSi2 heating rod | MoSi2 heating rod | MoSi2 heating rod | MoSi2 heating rod | MoSi2 heating rod | MoSi2 heating rod | MoSi2 heating rod | MoSi2 heating rod | MoSi2 heating rod |
| Thermocouple | Thermocouple | B type | B type | B type | B type | B type | B type | B type | B type | B type | B type | B type | B type |
| Chamber Material | Chamber Material | Alumina ceramic fiber | Alumina ceramic fiber | Alumina ceramic fiber | Alumina ceramic fiber | Alumina ceramic fiber | Alumina ceramic fiber | Alumina ceramic fiber | Alumina ceramic fiber | Alumina ceramic fiber | Alumina ceramic fiber | Alumina ceramic fiber | Alumina ceramic fiber |
| Electricity | Electricity | AC 220V, 50Hz/60Hz | AC 220V, 50Hz/60Hz | AC 220V, 50Hz/60Hz | AC 220V, 50Hz/60Hz | AC 220V, 50Hz/60Hz | AC 220V, 50Hz/60Hz | AC 220V, 50Hz/60Hz | AC 220V, 50Hz/60Hz | AC 220V, 50Hz/60Hz | AC 220V, 50Hz/60Hz | AC 220V, 50Hz/60Hz | AC 220V, 50Hz/60Hz |
Tim sales kami akan mengirimkan quotation lengkap (harga, lead time, biaya instalasi) dalam 1×24 jam kerja.
