| Spesifikasi | Specification | Specification | Specification | Specification | Specification | Specification |
|---|
| Skala ukur | Optical Rotation Specific Rotation Concentration International Sugar Scale User Defined | Optical Rotation Specific Rotation Concentration International Sugar Scale User Defined | Optical Rotation Specific Rotation Concentration International Sugar Scale User Defined | Optical Rotation Specific Rotation Concentration International Sugar Scale User Defined | Optical Rotation Specific Rotation Concentration International Sugar Scale | Optical Rotation Specific Rotation Concentration International Sugar Scale |
|---|
| Rentang ukur | ±90° (OR) ±259°Z (ISS) | ±90° (OR) ±259°Z (ISS) | ±90° (OR) ±259°Z (ISS) | ±90° (OR) ±259°Z (ISS) | ±90° (OR) ±259°Z (ISS) | ±90° (OR) ±259°Z (ISS) |
|---|
| Akurasi | ±0.003° | ±0.004° | ±0.004° | ±0.004° | ±0.004° | ±0.006° |
|---|
| Keterulangan | ≤0.002° | ≤0.002° | ≤0.002° | ≤0.002° | ≤0.002° | ≤0.002° |
|---|
| Transmisi min. | 0.01% | 0.1% | 0.1% | 0.05% | 0.1% | 0.1% |
|---|
| Resolusi | 0.0001° | 0.001° | 0.001° | 0.001° | 0.001° | 0.001° |
|---|
| Available wavelenght | 589nm | Standard: 589nm/880nm Optional: 365nm/405nm/436nm/546nm/578nm/633nm | Standard: 589nm/546nm Optional: 365nm/405nm/436nm/578nm/633nm | 589nm | 589nm | 589nm |
|---|
| Kecepatan respons | 8°/sec. | 8°/sec. | 8°/sec. | 8°/sec. | 8°/sec. | 8°/sec. |
|---|
| Waktu ukur | 6 times/26 sec. | 6 times/26 sec. | 6 times/26 sec. | 6 times/26 sec. | 6 times/26 sec. | 6 times/26 sec. |
|---|
| Rentang kontrol suhu | Peltier temperature control: 10℃ to 50℃ | Peltier temperature control: 10℃ to 50℃ | Peltier temperature control: 10℃ to 50℃ | Peltier temperature control: 10℃ to 50℃ | Peltier temperature control: 10℃ to 50℃ | / |
|---|
| Akurasi suhu | ±0.2℃ | ±0.2℃ | ±0.2℃ | ±0.2℃ | ±0.2℃ | / |
|---|
| Kalibrasi | Multi-point automatic calibration | Multi-point automatic calibration | Multi-point automatic calibration | Multi-point automatic calibration | Multi-point automatic calibration | Multi-point automatic calibration |
|---|
| User management permissions | Four levels | Four levels | Four levels | Four levels | / | / |
|---|
| Electronic signature | Yes | Yes | Yes | Yes | / | / |
|---|
| Jejak audit | Optional FDA software | Optional FDA software | Optional FDA software | Optional FDA software | / | / |
|---|
| Engineering | Engineering | Engineering | Engineering | Engineering | Engineering | Engineering |
|---|
| Sumber cahaya | LED (100,000 hours lifespan) Precision interference filter | LED (100,000 hours lifespan) Precision interference filter | Tungsten halogen lamp (20W) | LED (100,000 hours lifespan) Precision interference filter | LED (100,000 hours lifespan) Precision interference filter | LED (100,000 hours lifespan) Precision interference filter |
|---|
| Panjang sel sampel | Standard: 100mm (regular) 200mm (regular) 100mm (temperature control) Optional: 50mm (regular) 200mm (temperature control) | Standard: 100mm (regular) 200mm (regular) 100mm (temperature control) Optional: 50mm (regular) 200mm (temperature control) | Standard: 100mm (regular) 200mm (regular) 100mm (temperature control) Optional: 50mm (regular) 200mm (temperature control) | Standard: 100mm (regular) 200mm (regular) 100mm (temperature control) Optional: 50mm (regular) 200mm (temperature control) | Standard: 100mm (regular) 200mm (regular) 100mm (temperature control) Optional: 50mm (regular) 200mm (temperature control) | Standard: 100mm (regular) 200mm (regular) Optional: 50mm (regular) |
|---|
| Data teknis | Technical data | Technical data | Technical data | Technical data | Technical data | Technical data |
|---|
| Tampilan | 10.1″ color LCD touchscreen | 10.1″ color LCD touchscreen | 10.1″ color LCD touchscreen | 10.1″ color LCD touchscreen | 8″ color LCD touchscreen | 8″ color LCD touchscreen |
|---|
| Sistem operasi | Android | Android | Android | Android | / | / |
|---|
| Penyimpanan dalam | 128G | 128G | 128G | 128G | 10,000 sets of data | 10,000 sets of data |
|---|
| Manajemen pengguna | 500 | 500 | 500 | 500 | / | / |
|---|
| Manajemen metode | 1000 | 1000 | 1000 | 1000 | 30 | 30 |
|---|
| Antarmuka komunikasi | RS232, USB, U disk, Keyboard, Mouse, Wifi, Ethernet | RS232, USB, U disk, Keyboard, Mouse, Wifi, Ethernet | RS232, USB, U disk, Keyboard, Mouse, Wifi, Ethernet | RS232, USB, U disk, Keyboard, Mouse, Wifi, Ethernet | RS232, USB, U disk | RS232, USB, U disk |
|---|
| Connect PC, LIMS | Yes | Yes | Yes | Yes | Yes | Yes |
|---|
| Printer (opsional) | Thermal printer Stylus printer Wifi printer | Thermal printer Stylus printer Wifi printer | Thermal printer Stylus printer Wifi printer | Thermal printer Stylus printer Wifi printer | Thermal printer | Thermal printer |
|---|
| Catu daya | 220V±22V, 50Hz±1Hz, 200W | 220V±22V, 50Hz±1Hz, 200W | 220V±22V, 50Hz±1Hz, 200W | 220V±22V, 50Hz±1Hz, 200W | 220V±22V, 50Hz±1Hz, 200W | 220V±22V, 50Hz±1Hz, 200W |
|---|
| Dimensi produk (L×W×H) | 702mm×376mm×240mm | 702mm×376mm×240mm | 702mm×376mm×240mm | 702mm×376mm×240mm | 702mm×376mm×240mm | 702mm×376mm×240mm |
|---|
| Dimensi kemasan (L×W×H) | 880mm×530mm×490mm | 880mm×530mm×490mm | 880mm×530mm×490mm | 880mm×530mm×490mm | 880mm×530mm×490mm | 880mm×530mm×490mm |
|---|
| Berat bersih | 21kg | 21kg | 21kg | 21kg | 21kg | 21kg |
|---|
| Berat kotor | 36kg | 36kg | 36kg | 36kg | 36kg | 36kg |
|---|
