| Kapasitas (L) | 34 | 57 | 70 | 138 | 188 |
|---|
| Sirkulasi | Forced air convection | Forced air convection | Forced air convection | Forced air convection | Forced air convection |
|---|
| Dimensi (W*D*H) — Dalam (mm) | 340*320*320 | 420*350*350 | 400*360*500 | 550*450*560 | 600*550*570 |
|---|
| Luar (mm) | 630*570*500 | 830*710*700 | 540*550*870 | 845*700*730 | 890*730*780 |
|---|
| Suhu — Rentang (℃) | RT+10-250 | RT+10-250 | RT+10-250 | RT+10-250 | RT+10-250 |
|---|
| Suhu | RT+10-250 | RT+10-250 | RT+10-250 | RT+10-250 | RT+10-250 |
|---|
| Suhu — Fluktuasi (℃) | ±0.5 | ±0.5 | ±0.5 | ±0.5 | ±0.5 |
|---|
| Suhu — Resolusi (℃) | 0.1 | 0.1 | 0.1 | 0.1 | 0.1 |
|---|
| Suhu — Keseragaman (℃) | ±2.5% | ±2.5% | ±2.5% | ±2.5% | ±2.5% |
|---|
| Suhu — Sensor | PT100 | PT100 | PT100 | PT100 | PT100 |
|---|
| Pengendali | PID | PID | PID | PID | PID |
|---|
| Tampilan | LCD | LCD | LCD | LCD | LCD |
|---|
| Timer (min) | 1-9999 | 1-9999 | 1-9999 | 1-9999 | 1-9999 |
|---|
| Bahan — Dalam | Stainless steel | Stainless steel | Stainless steel | Stainless steel | Stainless steel |
|---|
| Bahan — Luar | High-quality cold-rolled steel plate surface anti-static spraying | High-quality cold-rolled steel plate surface anti-static spraying | High-quality cold-rolled steel plate surface anti-static spraying | High-quality cold-rolled steel plate surface anti-static spraying | High-quality cold-rolled steel plate surface anti-static spraying |
|---|
| Rak | 2 | 2 | 2 | 2 | 2 |
|---|
| Perangkat keselamatan | Leakage protector/Over- temperature alarm | Leakage protector/Over- temperature alarm | Leakage protector/Over- temperature alarm | Leakage protector/Over- temperature alarm | Leakage protector/Over- temperature alarm |
|---|
| Kelistrikan — Tegangan/frekuensi (V/Hz) | AC 220/110V,50/60Hz | AC 220/110V,50/60Hz | AC 220/110V,50/60Hz | AC 220/110V,50/60Hz | AC 220/110V,50/60Hz |
|---|
| Kelistrikan — Konsumsi (W) | 500 | 750 | 1050 | 1500 | 2000 |
|---|
| Berat bersih/berat kotor (kg) | 27/30 | 42/48 | 55/61 | 70/88 | 86/107 |
|---|
| Dimensi pengiriman (W*D*H)(mm) | 770*680*580 | 760*640*640 | 650*640*1030 | 810*900*960 | 990*860*940 |
|---|
| Standar | Shell:Laser operation | Shell:Laser operation | Shell:Laser operation | Shell:Laser operation | Shell:Laser operation |
|---|
| Standar | Inner tank: brushed stainless steel | Inner tank: brushed stainless steel | Inner tank: brushed stainless steel | Inner tank: brushed stainless steel | Inner tank: brushed stainless steel |
|---|
| Standar | Fan: built-in fan | Fan: built-in fan | Fan: built-in fan | Fan: built-in fan | Fan: built-in fan |
|---|
| Standar | Heating pipe: stainless steel heating pipe | Heating pipe: stainless steel heating pipe | Heating pipe: stainless steel heating pipe | Heating pipe: stainless steel heating pipe | Heating pipe: stainless steel heating pipe |
|---|
| Standar | Insulation: High-quality aluminum silicate silk cotton six-sided insulation | Insulation: High-quality aluminum silicate silk cotton six-sided insulation | Insulation: High-quality aluminum silicate silk cotton six-sided insulation | Insulation: High-quality aluminum silicate silk cotton six-sided insulation | Insulation: High-quality aluminum silicate silk cotton six-sided insulation |
|---|
| Standar | Electrical appliances: Leakage protector | Electrical appliances: Leakage protector | Electrical appliances: Leakage protector | Electrical appliances: Leakage protector | Electrical appliances: Leakage protector |
|---|
| Standar | Temperature control: with PID, timing, self-tuning, thyristor, LCD display | Temperature control: with PID, timing, self-tuning, thyristor, LCD display | Temperature control: with PID, timing, self-tuning, thyristor, LCD display | Temperature control: with PID, timing, self-tuning, thyristor, LCD display | Temperature control: with PID, timing, self-tuning, thyristor, LCD display |
|---|
| Opsional | Intelligent touch screen with program setting and data storage functions | Intelligent touch screen with program setting and data storage functions | Intelligent touch screen with program setting and data storage functions | Intelligent touch screen with program setting and data storage functions | Intelligent touch screen with program setting and data storage functions |
|---|
| Opsional | Printer or RS 485 port (choose one), independent temperature limit controller, test hole | Printer or RS 485 port (choose one), independent temperature limit controller, test hole | Printer or RS 485 port (choose one), independent temperature limit controller, test hole | Printer or RS 485 port (choose one), independent temperature limit controller, test hole | Printer or RS 485 port (choose one), independent temperature limit controller, test hole |
|---|
