| Jenis instrumen | Wet and Dry | Wet | Wet | Dry | Dry |
|---|
| Spesifikasi | Specification | Specification | Specification | Specification | Specification |
|---|
| Rentang ukur | Wet: 0.01μm to 2000μm Dry: 0.1μm to 2000μm | 0.01μm to 2000μm | 0.01μm to 1500μm | 0.1μm to 2000μm | 0.1μm to 1200μm |
|---|
| Fotodetektor | Wet: 127 Dry: 100 | 106 | 88 | 100 | 100 |
|---|
| Akurasi | Wet: ≤1% (CRM D50) Dry: ≤1% (CRM D50) | ≤0.5% (CRM D50) | ≤0.5% (CRM D50) | ≤1% (CRM D50) | ≤1% (CRM D50) |
|---|
| Keterulangan | Wet: ≤1% (CRM D50) Dry: ≤1% (CRM D50) | ≤0.5% (CRM D50) | ≤0.5% (CRM D50) | ≤1% (CRM D50) | ≤1% (CRM D50) |
|---|
| Prinsip desain | Laser Diffraction | Laser Diffraction | Laser Diffraction | Laser Diffraction | Laser Diffraction |
|---|
| Prinsip analisis | Mie Scattering Fraunhofer Diffraction | Mie Scattering Fraunhofer Diffraction | Mie Scattering Fraunhofer Diffraction | Mie Scattering Fraunhofer Diffraction | Mie Scattering Fraunhofer Diffraction |
|---|
| Standar | ISO 13320 | ISO 13320 | ISO 13320 | ISO 13320 | ISO 13320 |
|---|
| Jejak audit | Optional FDA software | Optional FDA software | Optional FDA software | Optional FDA software | Optional FDA software |
|---|
| Engineering | Engineering | Engineering | Engineering | Engineering | Engineering |
|---|
| Laser | Main Laser: Semiconductor Laser, 639nm, P>3mW Auxiliary Laser: 405nm, P>2mW | Main Laser: Fiber Laser, 632.8nm, P>4mW Auxiliary Laser: 650nm, P>10mW | Main Laser: Fiber Laser, 639nm, P>2mW Auxiliary Laser: 405nm, P>2mW | Semiconductor Laser, 632.8nm, P>2mW | Semiconductor Laser, 632.8nm, P>2mW |
|---|
| Keselamatan laser | Class 1 | Class 1 | Class 1 | Class 1 | Class 1 |
|---|
| Detektor | Log-spaced array 0.015° to 145° | Log-spaced array 0.015° to 145° | Log-spaced array 0.015° to 145° | Log-spaced array 0.015° to 145° | Log-spaced array 0.015° to 145° |
|---|
| Mode operasi | Full Automatic Manual Control | Full Automatic Manual Control | Full Automatic Manual Control | Full Automatic Manual Control | Full Automatic Manual Control |
|---|
| Optical alignment | Full Automatic | Full Automatic | Full Automatic | Full Automatic | Full Automatic |
|---|
| Kecepatan uji | Wet: ≤2min Dry: ≤1min Typical testing time: ≤10s Inverval time per test result: 500ms | ≤2min Typical testing time: ≤10s | ≤2min Typical testing time: ≤10s | ≤1min | ≤1min |
|---|
| Wet dispersion | Wet dispersion | Wet dispersion | Wet dispersion | Wet dispersion | Wet dispersion |
|---|
| Ultrasonik | Frequency: 40kHz Power: 60W Time: ≥1s | Frequency: 40kHz Power: 50W Time: adjustable | Frequency: 40kHz Power: 60W Time: adjustable | / | / |
|---|
| Pengaduk | Speed: 0rpm to 3000rpm adjustable | Speed: 0rpm to 3000rpm adjustable | Speed: 0rpm to 3000rpm adjustable | / | / |
|---|
| Circulate | Rated Flow: 30L/min Rated Power: 70W | Rated Flow: 30L/min Rated Power: 70W | Rated Flow: 3.6L/min Rated Power: 29W | / | / |
|---|
| Tangki sampel | Volume: 1000mL | Volume: 1000mL | Volume: 550mL | / | / |
|---|
| Micro-sample cuvette | Optional | Optional | Optional | / | / |
|---|
| Dispersi kering | Dry dispersion | Dry dispersion | Dry dispersion | Dry dispersion | Dry dispersion |
|---|
| Dispersi kering | Dry-turbulence dispersion, normal shock wave shear technique | / | / | Dry-turbulence dispersion mode, normal shock wave shear technique | Dry-turbulence dispersion mode, normal shock wave shear technique |
|---|
| Pengumpanan sampel | Automatic Sampler (knob setting) | / | / | Automatic Sampler (knob setting) | Automatic Sampler (knob setting) |
|---|
| Medium dispersi | Compressed Air | / | / | Compressed Air | Compressed Air |
|---|
| Data teknis | Technical data | Technical data | Technical data | Technical data | Technical data |
|---|
| Connect PC, LIMS | Yes | Yes | Yes | Yes | Yes |
|---|
| Laporan uji | Word, Excel, Image, Text, etc. | Word, Excel, Image, Text, etc. | Word, Excel, Image, Text, etc. | Word, Excel, Image, Text, etc. | Word, Excel, Image, Text, etc. |
|---|
| Lingkungan kerja | Temperature: 5℃ to 35℃ Humidity: <85% | Temperature: 5℃ to 35℃ Humidity: <85% | Temperature: 5℃ to 35℃ Humidity: <85% | Temperature: 5℃ to 35℃ Humidity: <85% | Temperature: 5℃ to 35℃ Humidity: <85% |
|---|
| Lingkungan penyimpanan | Temperature: -20℃ to 50℃ | Temperature: -20℃ to 50℃ | Temperature: -20℃ to 50℃ | Temperature: -20℃ to 50℃ | Temperature: -20℃ to 50℃ |
|---|
| Catu daya | 220V, 50/60Hz | 220V, 50/60Hz | 220V, 50/60Hz | 220V, 50/60Hz | 220V, 50/60Hz |
|---|
| Dimensi produk (L×W×H) | 1040mm×440mm×540mm | 1040mm×440mm×540mm | 1040mm×440mm×540mm | 1040mm×440mm×540mm | 1040mm×440mm×540mm |
|---|
| Berat bersih | 70kg | 58kg | 58kg | 58kg | 58kg |
|---|
