Metallurgical Microscope, MSC-M60X
MSC-M60X
Metallurgical Microscope MSC-M60X dilengkapi eyepiece bidang luas WF10X/FN 22 dengan diopter yang dapat disetel, nosepiece kuintuple, fungsi ECO mati otomatis dan voice broadcast, serta diafragma aperture, diafragma bidang, dan dudukan filter.
Yang akan anda dapatkan jika membeli Metallurgical Microscope, MSC-M60X dari kami
- ✓
Garansi Resmi Prinsipal
Unit didistribusikan resmi dengan garansi prinsipal sesuai ketentuan pabrikan.
- ✓
Instalasi & Training
Teknisi kami membantu instalasi dan pelatihan penggunaan alat di lokasi Anda.
- ✓
Dukungan Teknis & Sparepart
Layanan purna jual, konsultasi teknis, dan ketersediaan suku cadang.
- ✓
Opsi Kalibrasi
Tersedia layanan kalibrasi tertelusur untuk menjaga akurasi instrumen.
Spesifikasi Teknis
| Parameter | MSC-M60X |
|---|---|
| Main Frame | Infinity-corrected optical system, with ECO automatic light-off and voice broadcast function |
| Observation Tube | Fixed Trinocular head with high eye point, Interpupillary 50~75mm, Light split: 100/0 and 0/100 |
| Viewing Head | Siedentopf head, inclined at 45° |
| Eyepiece | Large field WF10X / FN 22, with adjustable diopter |
| Objectives | Semi-apochromatic brightfield metallurgical objective Plan Fluor EPI 5X/0.15, working distance 20 mm |
| Objectives | Semi-apochromatic brightfield metallurgical objective Plan Fluor EPI 10X/0.3, working distance 11 mm |
| Objectives | Semi-apochromatic brightfield metallurgical objective L Plan 20X/0.45, working distance 3 mm |
| Objectives | Semi-apochromatic brightfield metallurgical objective L Plan 50X/0.8, working distance 1 mm |
| Nosepiece | Inward-facing Quintuple Nosepiece; Ball-bearing positioning; Anti-fungus treatment. |
| Stage | X-Y mechanical metallographic stage; With water droplet plate; |
| Focusing | Coaxial coarse and fine adjustment, with locking and limit device, low-position coaxial focusing knob, fine division 2μm |
| Epi-illumination System | 3W full-spectrum white LED, continuously adjustable brightness With polarization kit for polarized light observation With aperture diaphragm, field diaphragm, and filter holder |
Fitur Utama
- Sistem optik infinity-corrected terintegrasi dengan iluminasi pantulan LED definisi tinggi.
- Sumber cahaya putih spektrum penuh dengan usia pakai sangat panjang dan suhu warna konstan.
- Mendukung pengamatan brightfield dan polarisasi, cocok untuk analisis spesimen logam berukuran besar.
