General Lab
SP-CLR520C Grating Portable Spectrophotometer mendukung kalibrasi otomatis, sudut pengamatan 2° dan 10°, ukuran integrating sphere φ40mm, interval panjang gelombang 10nm, dan rentang panjang gelombang 400-700nm.
Garansi Resmi Prinsipal
Unit didistribusikan resmi dengan garansi prinsipal sesuai ketentuan pabrikan.
Instalasi & Training
Teknisi kami membantu instalasi dan pelatihan penggunaan alat di lokasi Anda.
Dukungan Teknis & Sparepart
Layanan purna jual, konsultasi teknis, dan ketersediaan suku cadang.
Opsi Kalibrasi
Tersedia layanan kalibrasi tertelusur untuk menjaga akurasi instrumen.
Grating Portable Spectrophotometer ini memiliki konfigurasi performa yang tangguh sehingga pengukuran warna menjadi lebih profesional. Error antar-instrumen yang unggul menjamin konsistensi data pengukuran dari berbagai perangkat.
Dilengkapi kamera terintegrasi untuk melihat area pengukuran demi hasil uji yang akurat.
| Parameter | SP-CLR520C |
|---|---|
| Optical Geometry | D/8 (diffused illumination,8° viewing) SCI (specular component included) ，SCE (specular component excluded) |
| Integrating Sphere Size | φ40mm |
| Light Source | Full waveband balanced LED |
| Color Space and Index | Reflectance, CIE-Lab, CIE-LCh, HunterLab, CIE Luv, XYZ, Yxy, RGB, Color difference(ΔE*ab, ΔE*cmc, ΔE*94,ΔE*00),WI(ASTM E313-00,ASTM E313-73,CIE/ISO, AATCC, Hunter, Taube Berger Stensby), YI(ASTM D1925,ASTM E313-00,ASTM E313-73), Blackness(My,dM),Color Fastness, Tint,(ASTM E313-00),Color Density CMYK(A,T,E,M), Milm, Munsell, Opacity, Color strength |
| Illuminant | A,B,C,D50,D55,D65,D75,F1,F2,F3,F4,F5,F6,F7,F8,F9,F10,F11,F12,CWF,U30,U35,DLF,NBF,TL83,TL84 |
| Observer Angle | 2°,10° |
| Sensor | 256 pixel CMOS sensor |
| Calibration | Auto |
| Wavelength Interval | 10nm |
| Wavelength Range | 400-700nm |
| Measured Reflectance Range | 0-200% |
| Reflectance Resolution | 0.01% |
| Repeatability | Chromaticity value: Max. :dE*ab< 0.04 Average :dE*ab< 0.03 Standard deviation within ΔE*ab 0.02 (When a whiteboard measures 30 times every 5 seconds) Reflectance: Standard deviation < 0.1% |
| Measuring Aperture | MAV:Φ8mm/Φ11mm MAV:Φ4mm/Φ6mm MINI:1*3mm |
| Inter-instrument Error | ΔE*ab＜0.2 (BCRA Series Ⅱ, average measurement of 12 tiles，MAV/SCI) |
| Test Time | About 1s |
| Battery | Rechargeable, 8000 times continuous tests, 3.7V/3000mAh |
| Screen | 2.4-inch IPS full color screen |
| Interface | USB，Bluetooth |
| Illuminant Life Span | 1 million measurements in 10 years |
| Software Support | Android, IOS, Windows |
| Camera | With |
| External Dimension (L*W*H) | 77.8*53.2*185.7mm |
| N.W./G.W. | 0.3kg/1.5kg |
| Shipping Dimension (L*W*H) | 320*170*290mm |
Tim sales kami akan mengirimkan quotation lengkap (harga, lead time, biaya instalasi) dalam 1×24 jam kerja.
