General Lab
BEP-M510 dan BEP-M950 adalah Benchtop Conductivity/TDS Meter dengan kalibrasi 1–3 titik dan 1–5 titik, akurasi ±1% F.S dan ±0,5% F.S, kompensasi suhu otomatis, serta penguncian titik akhir otomatis.
Garansi Resmi Prinsipal
Unit didistribusikan resmi dengan garansi prinsipal sesuai ketentuan pabrikan.
Instalasi & Training
Teknisi kami membantu instalasi dan pelatihan penggunaan alat di lokasi Anda.
Dukungan Teknis & Sparepart
Layanan purna jual, konsultasi teknis, dan ketersediaan suku cadang.
Opsi Kalibrasi
Tersedia layanan kalibrasi tertelusur untuk menjaga akurasi instrumen.
• BEP-M510: Conductivity, TDS, suhu
• BEP-M950: Conductivity, TDS, salinitas, resistivitas, suhu
• CON-0.1: Cocok untuk mengukur cairan dengan conductivity rendah (<10 µS/cm)
• CON-1: Cocok untuk aplikasi kebutuhan umum
Geser tabel ke samping untuk melihat seluruh 3 varian model.
| Parameter | Model Range | BEP-M510 0.01~20.00, 200.0, 2000µS/cm, 20.00, 200.0mS/cm | BEP-M950 0.01~20.00, 200.0, 2000µS/cm, 20.00, 200.0mS/cm |
|---|---|---|---|
| Conductivity | Resolution | 0.001, 0.01, 0.1, 1 | 0.001, 0.01, 0.1, 1 |
| Conductivity | Accuracy | ±1% F.S. | ±0.5% F.S. |
| Conductivity | Calibration Points | 1 to 3 points | 1 to 5 points |
| Conductivity | Calibration Solutions | 10µS/cm, 84µS/cm, 1413µS/cm, 12.88mS/cm, 111.8mS/cm | 10µS/cm, 84µS/cm, 1413µS/cm, 12.88mS/cm, 111.8mS/cm |
| TDS | Range | 0~10.00, 100.0, 1000ppm, 10.00, 200.0ppt | 0~10.00, 100.0, 1000ppm, 10.00, 200.0ppt |
| TDS | Resolution | 0.01, 0.1, 1 | 0.01, 0.1, 1 |
| TDS | Accuracy | ±1%F.S. | ±1%F.S. |
| TDS | TDS Factor | 0.1~1.0 (default 0.5) | 0.1~1.0 (default 0.5) |
| Salinity | Range | — | 0.00~42.00psu, 0.00~80.00ppt |
| Salinity | Resolution | — | 0.01 |
| Salinity | Accuracy | — | ±1% F.S. |
| Resistivity | Range | — | 0.00~20.00MΩ |
| Resistivity | Resolution | — | 0.01 |
| Resistivity | Accuracy | — | ±1% F.S. |
| Temperature | Range | 0~105°C/32~221°F | 0~105°C/32~221°F |
| Temperature | Resolution | 0.1°C/0.1°F | 0.1°C/0.1°F |
| Temperature | Accuracy | ±1°C/±1.8°F | ±0.5°C/±0.9°F |
| Temperature | Offset Calibration | 1 point, reading ±10°C | 1 point, reading ±10°C |
| Other Specifications | Temperature Compensation | 0~100°C, manual or automatic | 0~100°C, manual or automatic |
| Other Specifications | Temperature Coefficient | Linear (0.0~10.0%/°C) | Linear (0.0~10.0%/°C), pure water |
| Other Specifications | Reference Temperature | 25°℃ | 20/25°C |
| Other Specifications | Cell Constant | K=0.1,1,10 or custom | K=0.1,1,10 or custom |
| Other Specifications | Stability Criteria | 一 | Low or high |
| Other Specifications | Calibration Due Alarm | 一 | 1 to 31 days or off |
| Other Specifications | Calibration Factor Display | 一 | Yes |
| Other Specifications | Hold Function | Manual or auto-endpoint | Manual or auto-endpoint |
| Other Specifications | Memory | 一 | 500 data sets |
| Other Specifications | Communication Interface | 一 | uSB |
| Other Specifications | Connector | 6-pin mini-DIN, 3.5mm jack socket | 6-pin mini-DIN,3.5mm jack socket |
| Other Specifications | Display | Custom LCD (120×60mm) | Custom LCD (125×100mm) |
| Other Specifications | Power Requirements | DC9V power adapter | DC5V power adapter |
| Other Specifications | Dimensions | 210(L)×205(W)×75(H)mm | 210(L)×188(W)×60(H)mm |
| Other Specifications | Weight | 1.5kg | 1.5kg |
Tim sales kami akan mengirimkan quotation lengkap (harga, lead time, biaya instalasi) dalam 1×24 jam kerja.
